Specifications:
Input Voltage: AC Input: 100-240V /DC Input: 11-18V
Controls: Enter/Start Rotary Dial, Mode/Stop Button
Bluetooth: Available
Display Type: 63.40*14.54mm LCD screen
Display Backlight: Blue
PC Communications: USB Port for PC Control & Firmware Upgrade
Case Material: Plastic
Cooling System: Bult-in, one 30*30*7mm fan
Case Size: 135*112*60.9mm
Weight: 525g
External Port: Temp Sensor, Servo/ESC Port, Brushless Motor Sensor Port, AC Input Power Port, Balance Socket,
USB Port for PC
Delta Peak Detection: NiCd: 3-15mV/cell
NiMH: 3-15mV/cell
Trickle Charge: 50-300mA
Charge Cutoff Temperature: 20-80°C (adjustable)
Charge Voltage: NiCd/NiMH: Delta peak detection
LiPo: 4.18-4.3V/cell
LiIon: 4.08-4.2V/cell
LiFe: 3.58-3.7V/cell
Balance Current: 200mA/cell
Reading Voltage Range: 0.3-5.0V/cell
Battery Types/Cells: NiCd/NiMH: 1-15cells
LiPo/LiIon/LiFe: 1-6cells
Pb: 2-20V
Battery Capacity Range: NiCd/NiMH: 0.1-1.1V/cell
LiPo/LiIon/LiFe: 100-50,000mAh
Pb: 100-50,000mAh
Charge Current: 0.1-10.0A
Safety Timer: 1-720 minutes, Off
Charge Wattage: AC50W, DC80W
Discharge Current: 0.1-5.0A(±10%)
Discharge Cut-off Voltage: NiCd/NiMH: 0.1-1.1V/cell
LiPo: 3.0-3.3V/cell
LiIon: 2.9-3.2V/cell
LiFe: 2.6-2.9V/cell
Pb: 1.8V
Discharge Wattage: 8W
Balance Cells: 6 cells
Memory: 10 different charge/discharge profiles
Charge Method: CC/CV for lithium types and lead (pb) batteries, Delta-peak Sensitivity for NiMH/NiCd.
